Hydraulic, Three point, Implement Parts for John Deere Model 1010


Controls and Linkage with hydraulic lines for Remote Control Valve Assembly

I have two complete units, including the hydraulic lines

Unit 1:

The above unit #1 came from a 40U and the five hydraulic lines (AM2423T, AM2424T, AM2425T, AM2426T, and AM2427T) will fit either a U or an S. With some modifications, the lines should fit other models as well. The M2658T control valve bracket has been replaced with a shop built bracket. The last photo show the unit mounted on the tractor before disassembly. $225


Unit 2:

Above photo is complete unit with all parts. Photos below are closeups of these parts.



Complete remote hydraulic control #2, includes M3352T, AM3514T, and AM3515T hydraulic lines. The M2615T draft control rod bracket has a welded repair and is fully funcitonal; otherwise, no breaks or repairs. This unit came from a 1010 wheel tractor. $275 (45/26-12-12)

AA3754R Plug bracket, $10

AT13586T (Labelled 2HCS9-1R) Hydrualic pump, tested and pumps well, $200

- -

T14656T hydraulic pump adaptor with T14421T pump driven gear (21T), $45

T15883T hydraulic line

T15396T elbow with M3250T flange, $15

Hydraulic line AT14148T, $30

AT13587T Oil line to power steering valve, $30

AT13588T Oil line to power steering valve, $30


T18502T (M3245T) Front cover and M3378T (AM3004T) Cylinder and valve housing with added parts as shown in the photo, $200, all looks to be in very good condition, can ship UPS

M3228T spacer, $5

AM1917T Right control lever with knob, $15

AM1916T Left control lever with knob, $15

T11267T equalizing lever and link, $20

M3170T control rod with AM1924T ball joint assembly and AM1925T ball joint assembly, $20

T10313T anchor, $5
T10314T spring

M1820T Quadrant, $30

M2101T Segment (two pieces), $25

M2137T Right crank arm with M554T connecting rod, $25

M2138T Left crank arm with M554T connecting rod, $25


T12735T Rockshaft housing (AT11949T) $75

M2005T rockshaft, $40

AM1922T Hollow rockshaft, $35


M2851T left lift arm, $25

M3167T inner lift arm, $25

M3166T right lift arm, $25

T11297T special bolt and 24H1374A flat washer (to hold arms to rockshaft), $9 per set

M3168T Return springs on three point hitch, $15 each

M2212T spring, $30

T15957T Anchor yoke, $25

M3171T control arm, $25

Adjustable lift link ( with M2437T housing), $125

Fixed lift link (with AM1896T link), $75

AM2713T Left side draft link, $40

AM2715T Right side draft link, $40

M3140T Trunnion bolts, with nuts, $40 each, two available

AM14162T Drawbar support assembly, no cuts or repairs, $75

Sway chain with M1702T anchor and M2876T front anchor, $25

Sway chain with M1702T anchor and home made front anchor, $15

M2084T bolt and nut used on sway chain, $15 each
